Description

• 12.5 mm (1/2”) drive
• Extra short: Length 115 mm
• High performance jumbo hammer mechanism
• Fatigue-proof work due to low net weight
• Single handed switching for clockwise/anticlockwise running
• Very low vibration
• Threefold torque selection
• With non-slip handle
• 1/4” inlet nipple included

Technical data

Abtriebs-Vierkant [mm]	12,5 (1/2")
Release Torque [Nm]	1200
Operating Mode	Pneumatic
Baulänge [mm]	115
Quality	Premium
Luftverbrauch [l/m]	170
Max. torque, 1. speed [Nm]	205
Max. Torque, 2nd speed	495
Max. Torque, 3rd speed	750
Service Speed [1/min]	11000
Operating Pressure [bar]	6,3
Thread Size, compressed air connection	1/4
Geräuschpegel [db(A)]	90
Sound Power Level [dB]	101
Vibration Acceleration [m/s²]	6.80000
Weight [kg]	1,2

Documents

Operating manual
Aug. 10, 2020, 9:15 p.m.

Spare and wear parts

	Item no.	variant	Name
	S3246-1	-	Retaining ring for all, 1/2”
